Utilize
Available
Downloads

Download Version One

1 PD 7, positioner digital solid with 7 mm bar

2 PD 10, positioner digital solid with 10 mm bar

3 NP PA 0, positioner analog 0 degrees solid ver 1

4 NP PA 3, positioner analog 3 degrees solid ver 1

5 NP PA 7, positioner analog 7 degrees solid ver 1

6 RP PA 0, positioner analog 0 degrees solid ver 3

7 RP PA 3, positioner analog 3 degrees solid ver 3

8 RP PA 7, positioner analog 7 degrees solid ver 3

9 DS NP drill sleeve H frame angled 4.15 mm hole, 5.5 mm wide

10 DS NP drill sleeve H frame straight 4.15 mm hole, 5.5 mm wide

11 DS RP drill sleeve H frame angled 5.1 mm hole, 7 mm wide

12 DS RP drill sleeve H frame angled 5.1 mm hole, 7 mm wide

Download Version Two

1 PD 7 positioner digital solid with 7 mm bar

2 PD 10 positioner digital solid with 10 mm bar

3 NP PA 0 positioner analog 0 degrees solid

4 RP PA 0 positioner analog 0 degrees solid

5 NP base angled 4.15 mm hole

6 NP base straight 4.15 mm hole

7 RP base angled 5.1 mm hole

8 RP base straight 5.1 mm hole

9 NP insert 3 degree 4-15 bore with 3 degree marking

10 NP insert 7 degree 4-15 bore with 7 degree marking

11 RP insert 0 degrees 5.05 bore ver 1

12 RP insert 3 degree 5-05 bore with 3 degree marking

13 RP insert 7 degree 5-05 bore with 7 degree marking
